Positionable Male Elbow

Get a Price/Quote

MOQ : 100 Pieces

Positionable Male Elbow Specification

Product Type
Positionable Male Elbow

Material
Brass, Nickel Plated or Stainless Steel

Type
Pneumatic Fitting

Shape
Elbow (90 Degree)

Technique
Precision CNC Machined

Surface Treatment
Nickel Plated, Polished Finish

Standard
ISO 9001:2015, DIN/ANSI Standard Compatible

Outer Diameter
8 mm, 10 mm, 12 mm, 14 mm (varies by model)

Length
Variable (depends on model and configuration)

Inside Diameter
6 mm, 8 mm, 10 mm, 12 mm (varies by model)

Wall Thickness
1.5 mm - 2 mm

Tensile Strength
up to 400 MPa (brass), up to 700 MPa (stainless steel)

Grade
CW614N Brass / 304 Stainless Steel

Size
1/8 to 1/2 BSPT/NPT (as per order)

Color
Silvery/Brass Golden

Connection Type
Push-in and Male Thread

Installation
Quick and tool-less assembly, positionable design

Max Working Temperature
-20C to +80C

Working Pressure
0 - 15 bar (0 - 215 psi)

Seal Material
NBR/Viton O-ring inside

Thread Type
BSPT, NPT, Metric thread available

Rotatability
360-degree rotatable elbow

Application
Used for pneumatic piping in automation lines, machinery, and industrial systems

Media
Air, Inert Gases

Positionable Male Elbow Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Positionable Male Elbow

Discover the Featured Positionable Male Elbow-engineered for supreme performance in industrial automation. Experience formidable strength with brass or durable 304 stainless steel, obeying ISO 9001:2015 and DIN/ANSI standards. This dominant pneumatic fitting offers best price and reliable installation with its tool-less, quick connect push-in and male thread options. Supporting BSPT, NPT, and Metric threads, and rotatable 360 for total control, it handles air or inert gases from -20C to +80C, with tensile strength up to 700 MPa. Try Now and equip your systems with an unrivaled, precision CNC-machined elbow!

Special Features and Material Excellence of Positionable Male Elbow

The Positionable Male Elbow stands out with its 360-degree rotatable design, enabling flexible orientation during installation. Crafted from supreme brass (CW614N) or 304 stainless steel, this fitting features an NBR/Viton O-ring for exceptional sealing. Its formidable build ensures long-lasting performance in demanding pneumatic piping for automation lines, machinery, and industrial systems. Quick, tool-less assembly saves invaluable time, while its polished finish adds durability and style, making it the preferred choice for dominant industrial operations.

Certifications, Supply Capabilities, and Transaction Terms for Positionable Male Elbow

Our Positionable Male Elbow meets the strictest ISO 9001:2015 certification standards and is compatible with DIN/ANSI regulations. We proudly offer this product with excellent supply ability for bulk orders, ensuring timely shipped goods to domestic and global destinations. As an established exporter, manufacturer, and supplier in India, we provide flexible payment terms. Freight arrangements are efficiently managed, delivering renowned reliability and best price value for all customers.

FAQ's of Positionable Male Elbow:

Q: How does the positionable design of the male elbow benefit my installation process?

A: The 360-degree rotatable feature allows precise alignment during installation, ensuring optimal hose orientation and simplifying assembly, even in tight spaces.

Q: What types of media are compatible with this pneumatic elbow fitting?

A: This fitting is designed for use with air and inert gases, making it highly versatile for various pneumatic applications in automation and industrial systems.

Q: When should I choose brass versus stainless steel for my application?

A: Choose brass (CW614N) for general industrial environments requiring high tensile strength (up to 400 MPa), or 304 stainless steel for superior corrosion resistance and greater tensile strength (up to 700 MPa) in harsher conditions.

Q: Where can Positionable Male Elbows be utilized?

A: These elbows are primarily used in pneumatic piping on automation lines, machinery, and various industrial systems that demand durable and flexible connections.

Q: What thread types and sizes are available for these elbows?

A: They are supplied with BSPT, NPT, and Metric thread options, ranging from 1/8 to 1/2, and can be matched to suit specific order requirements.

Q: How is the product shipped and what payment terms are available?

A: We offer flexible payment terms, efficient freight handling, and ensure quickly shipped goods for both domestic and international orders, catering to bulk and specific requests alike.
