Thermocouple Connector

Get a Price/Quote

MOQ : 100 Pieces

Thermocouple Connector Specification

Product Type
Thermocouple Connector

Material
Plastic & Metal (Brass/Copper Pins)

Type
Standard Miniature (K/J/T/E/R/S/N)

Shape
Rectangular

Technique
Injection Moulded

Surface Treatment
Smooth Finish

Standard
ANSI/IEC Thermocouple Standards

Length
Approx. 40mm

Grade
Industrial

Size
Mini and Standard

Color
Yellow (Type K), Other colors for different types

Connection Type
Screw Type

Maximum Operating Temperature
220C

Installation
Panel/Field Mountable

Number of Pins
2

Compatible Cable Size
up to 2.5 mm2

Contact Pin Material
Nickel-plated Copper

Polarity Marking
Clearly Marked (+/-)

Weight
Approx. 12g

Insulation Resistance
>500 M @ 500V DC

Application
Thermocouple & RTD Wiring

Thermocouple Connector Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Thermocouple Connector

Unlock impeccable connectivity and capitalise on the splendiferous reliability of our Thermocouple Connector-expertly engineered with nickel-plated copper contact pins and robust plastic-metal construction. Designed for excellence, it holds a noteworthy maximum operation temperature of 220C and accommodates cables up to 2.5 mm2. The clearly marked polarity (+/-), screw-type connection, and panel/field mountable flexibility ensure seamless installation. Adhering to ANSI/IEC standards, this versatile connector is ideal for thermocouple and RTD wiring-offering smooth surface treatment, exceptional insulation resistance, quick access, and unmatched industrial grade strength. Available in yellow and other colors for various types.

Versatile Applications & Competitive Advantages

Our Thermocouple Connector thrives in a broad spectrum of applications, from laboratory instrumentation and plant automation to process control and thermal measurement setups. Trusted by leading industries for its noteworthy compatibility with various thermocouple types (K/J/T/E/R/S/N), this connector ensures impeccable, error-free connections. Capitalise on its robust construction, high insulation resistance, and panel or field mounting options-outmatching common alternatives in durability, reliability, and user-friendly design, making it a preferred choice for both plant and field use.

Swift Payment Processing & Reliable Delivery

Experience hassle-free transactions with flexible payment terms designed for client convenience. Our main domestic market spans across India, serving both urban and industrial zones. We assure quick dispatch and efficient transportation, ensuring your connectors are dispatched promptly and delivered within a minimal lead time. Whether you require bulk supplies or urgent replacements, our streamlined processes guarantee rapid fulfillment and peace of mind, ensuring your operations continue smoothly with minimal interruption.

FAQ's of Thermocouple Connector:

Q: How do you install the thermocouple connector in a panel or field application?

A: Installation is straightforward-simply follow the panel or field mounting option, use the screw-type connections for secure wiring, and ensure proper cable placement (up to 2.5 mm2). The clearly marked polarity makes aligning the pins a seamless process for rapid, error-free setup.

Q: What are the primary benefits of using nickel-plated copper contact pins?

A: Nickel-plated copper contact pins offer excellent conductivity, corrosion resistance, and extended longevity, delivering impeccable and stable connections for thermocouple and RTD wiring even at elevated temperatures up to 220C.

Q: When should I use this miniature thermocouple connector over others?

A: This connector is ideal when you need reliable operation in harsh industrial or laboratory environments, compatibility with a wide range of thermocouple types, and a need for rapid installation backup-with industrial-grade performance and adherence to ANSI/IEC standards.

Q: Where is this connector typically used in plant applications?

A: It is commonly implemented in process control, temperature monitoring, and automation systems in plants and labs, ensuring precise and stable thermocouple or RTD wiring connections for critical instrumentation.

Q: What is the insulation resistance, and why is it important?

A: The insulation resistance rating exceeds 500 M at 500V DC, which means it provides noteworthy protection against electrical leakage-ensuring safe operation, signal integrity, and preventing interference during temperature measurements.
